Description
The security business has evolved beyond simple intrusion detection and surveillance monitoring. The use of Ethernet networks and the Internet of Things (IoT) can now take door switch data and notify users that it is open or closed, whether they are on site or not. A thermostat control or CCTV camera can send its data off-site to users as well.
Features
- CMR
- 22 AWG 4 Conductors
- Stranded Bare Copper Conductor
- Shielded Cable with Jacket
- Polyvinyl Chloride Insulation Material, PVC Jacket
- NEC Article 800, UL Subject 444
- 140°F Max
- 1000' Pull Box
- Jacket Color: Grey
- Two conductor shielded cable used for communication applications
Specifications
Electricals
- Suggested Working Voltage - 300 Volts, rms
Technical Details
- Temperature Rating
- Operation - -20°C to +60°C
- Nominal Weight - 17 lbs. / 1,000 ft
Standards
- NEC Article 800
- UL Subject 444
- CMR Type FT4
Codes & Listings
- C(ETL)US CMR FT4
