Description
| Male Plug | NEMA L6-30 |
| Female Connector | IEC320 C19 |
| Leg Count | 5 |
| Leg Length | 24 Inch |
| Voltage | 250 Volts |
| Amperage | 20 Amps |
| Cable Length | 3.0 Meter / 10 Feet |
| Tolerance | ± 50 mm / ± 2 inches for molded cords ± 100 mm / ± 4 inches for mechanical cords |
| Conductor Size | 10 & 12 Gauge AWG |
| Conductor Count | 3 wires |
| Conductor Color Code | Black, White, Green | North American Color Code (NACC) |
| Outside Diameter | 15.9-16.5mm, 11.0-11.4mm for legs |
| Cable Jacket | North America SJT |
| Jacket Material | PVC |
| Jacket Temperature Rating | 105° C |
| Color | Black |
| Testing | Each cord is tested for dielectric voltage-withstand (Hi-Pot), polarization and continuity. |
| Certification(s) | US & Canada - cULus |
| Packaging | Loose & Bundled |
| Weight | 3.04 lbs |
