Description
Designed to thermomechanically remove coatings from optical fibers with cladding, this thermal stripper is perfect for stripping extremely difficult or baked-on coatings with ease. This thermal stripper also features the following:
- Heater is adjustable up to 200°C, far hotter than any competing product
- Has the ability to remove some fluoroacrylate undercoatings using high temperature
- Adjustable temperature and time settings allow it to adapt to a wide range of acrylate coatings and cladding sizes
- Supports optical fibers with cladding diameter of 125 µm, with buffer diameters from 250 µm to 900 µm, including 250 µm, 400 µm, and 900 µm coated fibers
- Compact and low-maintenance benchtop design makes this easy and convenient to use
- Compatible with Fitel, Fujikura, and Ericsson fiber holder platforms, and a Universal Clamp for LDF or any other type of fiber (each sold separately)
- Includes: Fixed Thermal Stripper, Power Supply, Power Cord, Cleaning Brush
Specifications +
| Blade Type | Fixed |
|---|---|
| Supported Fiber Buffers | 250 µm-900 µm |
| Supported Fiber Types | 125 µm cladding |
| Adjustable Temperature Range | 60°C-200°C, or ambient |
| Adjustable Heat Time Range | 0-30 seconds (2 second increments) |
| External Power Supply | 100-240 VAC, 47-63 Hz |
| Dimensions | 5.1" x 2.9" x 2.8" (129.5 mm x 73.5 mm x 71 mm) |
| Weight | 0 lb (0 g) |
| UPC # | 811490011236 |
| Data Sheet | Download Data Sheet | TSFB-125 |
