Description
Key Features
- Ideally suited for mounting printed circuit boards or components.
- Choice of two materials:
- General purpose ABS with a flame rating of UL94-HB
- Polycarbonate with a flame rating of UL94-V2
- Gasketed lid with two piece "tongue & groove" construction provides protection against access of oil, dust, and water.
- Rubber gasket is included and must be field installed.
- Lid includes smooth recessed area for membrane, label or silkscreen.
- Designed to meet IP 65.
- Lid is secured with self captivating M3.5 stainless steel machine screws (included), threaded into corrosion resistant bushings (for repetitive assembly & disassembly).
- Lid screws are self captivating (lid holes are threaded with the first installation of lid screws).
- Internal features are maximized for mounting options:
- Internal DIN rail mounting tabs
- PC board mounting posts
Specifications
| Packaging Type | bag |
|---|---|
| Material | Polycarbonate |
| Color | Light Gray |
| Flame Rating | UL94 V-2 |
| IP Rating | IP65 |
| Product Category | Enclosures |
| Type | General purpose, water-tight |
| Max. P.C. Board Length (mm) | 92 |
| Max. P.C. Board Width (mm) | 62 |
