Description
Bussmann TCF90RN Time Delay Fuse
Bussmann CUBEFuse Time Delay Fuse, Non-Indicating, Series: TCF, 90 A, 600 VAC/300 VDC, 100/300 kA Interrupt, Class: CF, 10 s at 500% Response, Blade Terminal, Chassis/DIN Rail Mount, Cartridge Body Type, Dual Element, Glass Filled Polyethersulfone, 1.06 in Dia x 5.5 in L Body Size
Additional Description: BUSS-TCF90RN CUBEFUSE, TCF 90A NON-IND
Catalog Description: Eaton Bussmann series TCF fuse, 90 A, 60 Hz, 50 Hz, Dual, CF, Black, Non-indicating, Blade end, Time delay, 10 sec at 500%, 300 kAIC at 600 V,100 kAIC at 300 Vdc, Glass filled PES, Chassis,35 mm DIN rail, 600 V, 300 Vdc
Specifications
| UNSPSC | 39121606 |
|---|---|
| Amperage Rating | 90 |
| Amperage Rating | 90 A |
| Body Type | Cartridge |
| Class | CF |
| Interrupt Rating | 100/300 |
| Interrupt Rating | 100/300 kA |
| Interrupt Rating | 300 |
| Interrupt Rating | 50/200/300 |
| Material | Glass Filled Polyethersulfone |
| Mounting type | Chassis/DIN Rail |
| Response Time | 10 |
| Response Time | 10 s at 500% |
| Series | TCF |
| Terminal Type | Blade |
| Terminal Type | Plug-In |
| Terminal Type | Radial Blade Plug In |
| Type | Non-Indicating |
| Voltage Rating | 600 VAC, 300 VDC |
| Voltage Rating | 600 VAC/300 VDC |
| Voltage Rating | 600/300 |
