Description
Bussmann TB400-12 Terminal Block
Bussmann Terminal Block, 12-Pole Double Row, Series: TB400, 600 V, 75 A, 14 to 6 AWG Wire, 0.687 in Center Spacing, #10-32 Screw, 20 in-lb, Panel Mount, Phillips Slot Screw, -40 to 130 deg C, Thermoplastic, Black, 9.39 in L x 1.12 in W x 0.46 in H
Additional Description: BUSS-TB400-12 BARRIER BLOCK
Catalog Description: Eaton Bussmann TB400 series panel mount terminal block connector, Breakdown voltage 7500V, 600V, 75A, Double row, barrier, Twelve-pole, #10-32 TPI Screw, Screw, Black, Tin-plated brass terminal, Zinc-plated Steel philslot screw
Specifications
| UNSPSC | 39121410 |
|---|---|
| Amperage Rating | 75 |
| Amperage Rating | 75 A |
| Color | Black |
| Connection type | Philips Slot Screw |
| Connection type | Phillips Slot Screw |
| Connection type | Phillips® Slot Screw |
| Dimensions | 9.39 in L x 1.12 in W x 0.46 in H |
| Material | Thermoplastic |
| Mounting type | Panel |
| Screw Size | #10-32 |
| Series | TB400 |
| Temperature Rating (Degrees F) | -40 to 130 |
| Temperature Rating (Degrees F) | -40 to 130 deg C |
| Torque Rating | 20 |
| Torque Rating | 20 in-lb |
| Type | 12-Pole Double Row |
| Voltage Rating | 600 |
| Voltage Rating | 600 V |
| Wire Size | 14 to 6 |
| Wire Size | 14 to 6 AWG |
