Description
Bussmann NDN111-BK Terminal Block
Bussmann Terminal Block, Series: NDN, 600 V, 90 A, 3 Pole, 18 to 2 AWG Wire, Feed-Through Terminal, 16.31 mm Spacing, 32 in-lb, C-Rail/DIN Rail Mount, Screw, 105 deg C, Thermoplastic, Black, 1.87 in W x 1.44 in D x 1.71 in H
Additional Description: BUSS-NDN111-BK (N) ASSEMBLY NO. 15201-13 NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series NDN DIN-rail feedthrough, 600V, 90A, Three-pole, 1/4 in-28 TPI Screw, 35 mm DIN rail, C-rail, base, Black
Specifications
| UNSPSC | 39121410 |
|---|---|
| Amperage Rating | 90 |
| Amperage Rating | 90 A |
| Color | Black |
| Connection type | Screw |
| Dimensions | 1.71 in H x 1.87 in W x 1.44 in D |
| Dimensions | 1.87 in W x 1.44 in D x 1.71 in H |
| Material | Thermoplastic |
| Mounting type | C Rail/DIN Rail |
| Mounting type | C-Rail/DIN Rail |
| Number of Poles | 3 |
| Series | NDN |
| Spacing | 16.31 |
| Spacing | 16.31 mm |
| Temperature Rating (Degrees F) | 105 |
| Temperature Rating (Degrees F) | 105 deg C |
| Terminal Type | Feed-Through |
| Torque Rating | 32 |
| Torque Rating | 32 in-lb |
| Voltage Rating | 600 |
| Voltage Rating | 600 V |
| Wire Size | 18 to 2 |
| Wire Size | 18 to 2 AWG |
