Description
Bussmann 170M4809 High Speed Fuse
Bussmann High Speed Fuse, Type 00/80, Series: 170M, Non-Indicating, 80 A, 1000 V, 125 kA Interrupt, Class: aR, 45 to 1000 Hz Frequency, Blade End x Din 43-620 Blade End Terminal, DIN 43-653 Stud Mounting, Square Body, Ceramic, 98 mm L x 30 mm W x 51 mm H Body
Additional Description: BUSS-170M4809 (N) FUSE 80A 1000V 00/80 AR NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series high speed square body fuse,80A,125 kAIC,Class aR,Blade end X Din 43-620 blade end,DIN 43 620,Standard,Clearing at 1000V: 3500,square body with centre-bolted tags (slotted),Top fuse status indicator,500,22W
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 80 |
| Amperage Rating | 80 A |
| Body Type | Square |
| Class | AR |
| Frequency Rating | 45 to 1000 |
| Frequency Rating | 45 to 1000 Hz |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 125 kA |
| Interrupt Rating | 150 |
| Material | Ceramic |
| Mounting type | DIN 43-653 Stud |
| Mounting type | Stud |
| Series | 170M |
| Terminal Type | Blade |
| Terminal Type | Blade End x Din 43-620 Blade End |
| Type | Type 00/80 |
| Voltage Rating | 1000 |
| Voltage Rating | 1000 V |
