Description
New keyed LC Limited Axcess™ connectors offer limited accessibility to networks through a physically restrictive cross connect system. By utilizing the new Limited Axcess LC fiber optic connectors, network administrators can easily segregate networks for security or confidentiality concerns.
Standard Colors: Red, Blue, Green & Yellow
| Connector Side A | LC/UPC | Connector Side B | LC/UPC |
| Ferrule Type Side A | 1.25mm | Ferrule Type Side B | 1.25mm |
| Insertion Loss Maximum Side A | ≤0.20dB | Insertion Loss Maximum Side B | ≤0.20dB |
| Insertion Loss Typical | 0.08dB | Insertion Loss Typical | 0.08dB |
| Return Loss | ≥20dB | Return Loss | ≥20dB |
| =============== | ==================== | ================== | ================== |
| Cable Type | OM3 50/125μm | Wavelength | 850/1300nm |
| Fiber Count | 2 | Fiber Grade | Corning ClearCurve Glass |
| Polarity | Rollover (Type B) | Cable Outer Diameter | 1.8mm Duplex Zip |
| Cable Jacket | OFNR Riser | Sub Unit Outer Diameter | N/A |
| Bend Radius, No Load | 10x cable overall diameter | Bend Radius, Load | 15x cable overall diameter |
| =============== | ==================== | ================== | ================== |
| 1 GbE Distance Max. | 10 GbE Distance Max. | 40 GbE Distance Max. | 100 GbE Distance Max. |
| 1,100 Meters | 300 Meter | 100 Meter | 100 Meter |
| Operating Temperature | 0° to 70°C (32° to 158°F) | Storage Temperature | -40° to 70°C (-40° to 158°F) |
Features
- Multimode OM3
- Standard cable is aqua-colored
- Cable assemblies using the latest in LED-ready glass
