| IT023xxHDNU AIT023 | | View DataSheet |
|---|
| Solder pin length: | 3.4 mm |
|---|---|
| min. number of poles: | 1 |
| max. number of poles: | 24 |
| Insulating material class: | CTI 600 |
| clearance/creepage dist.: | 2.3 mm |
| Protection category: | IP20 |
| wire insulation: | 1.8 mm |
| Connection capacity (single-wire): | 0,2 - 0,34 mm² |
|---|---|
| Connection capacity (single-wire): | AWG 24 - 22 |
| Connection capacity (multi-wire): | 0,2 - 0,34 mm² |
| Connection capacity (multi-wire): | AWG 24 - 22 |
| insulating material: | PA66 |
|---|---|
| flammability class: | V0 |
| contact material: | CuSn |
| Contact surface: | Sn |
| Glow-Wire Flammability GWFI: | 850 °C acc. to IEC 60695-2-12 |
| Glow-Wire Flammability GWIT: | 775 °C acc. to IEC 60695-2-13 |
| upper limit temperature: | 105 °C |
|---|---|
| lower limit temperature: | -40 °C |
