In Stock
Metz Connect

Metz Connect 360158. Type 360158

No reviews yet Write a Review
$0.60
Metz Connect 360158 Type 360158 | American Cable Assemblies
Metz Connect 360158. Type 360158
Metz Connect 360158. Type 360158
SKU:
MTZ360158
UPC:
4.25E+12
Minimum Purchase:
1 unit
Current Stock:
Mounting style:
reflow solderable (THR)
Centerline:
Single poles
Direction of connection:
0 °
Connection capacity single-wire:
0,52 - 4,0 mm²
Connection capacity multi-wire:
0,52 - 4,0 mm²
RoHS:
compliant
EAN:
4251122156618
$0.60

Frequently Bought Together:

Metz Connect 360158 Type 360158 | American Cable Assemblies
Inc. Tax
Ex. Tax

Description

  • screw type terminal block, THR solderable, double solder pins
  • direction of connection vertical 0°
  • color metallike
  • Tape & Reel packaging
  • screw completely hand-screwed

Resources

Type 360158 | 360158View DataSheet

Specifications

General Data
Tightening torque SEV: 0.5 Nm
Tightening torque UL: 4.4 lb-in
Solder pin length: 4.2 mm
min. number of poles: 1
max. number of poles: 1
Protection category: IP00
Rated current: 20 A
Connection Data
Connection capacity (single-wire): 0,52 - 4,0 mm²
Connection capacity (single-wire): AWG 20 - 10
Connection capacity (multi-wire): 0,52 - 4,0 mm²
Connection capacity (multi-wire): AWG 20 - 10
Material
terminal body material: CuZnPb
terminal body surface: Ni + Sn
screw surface: Zn Cr(VI)-frei/free
terminal body thread: M3,5
