Sold Out
Metz Connect

Metz Connect 151SX8F8F0XXY. OpDAT patch cord MTP-F/MTP-F OM4, 8 fibres

No reviews yet Write a Review
$0.00
Metz Connect 151SX8F8F0XXY OpDAT patch cord MTP-F/MTP-F OM4, 8 fibres | American Cable Assemblies
Metz Connect 151SX8F8F0XXY. OpDAT patch cord MTP-F/MTP-F OM4, 8 fibres
Metz Connect 151SX8F8F0XXY. OpDAT patch cord MTP-F/MTP-F OM4, 8 fibres
SKU:
MTZ151SX8F8F0XXY
Availability:
Call for pricing and availability
Minimum Purchase:
1 unit
Current Stock:
Cable type:
MPO/MTP® cable
Fiber type:
OM4
Interface 1:
MPO/MTP®
Interface 2:
MPO/MTP®
RoHS:
compliant

Frequently Bought Together:

Inc. Tax
Ex. Tax

Description

  • patch cord with 8 OM4 fibers, assembled on both sides with MPO/MTP® connectors, violet housing color
  • with MM-Elite® ferrules
  • Female connectors (without pins) as standard. Variants with male connectors (with pins) are possible.
  • available in assignment variants polarity A or B
  • suitable for transmissions of e.g. 4x25 Gbit/s (depending on transceiver technology)
  • Cable with aramid fabric, suitable for indoor applications. Diameter available in Ø 2.0 mm and Ø 3.0 mm, sheath color violet, UV stabilized, flame retardant and halogen free.
  • Fiber type: Bend insensitive multi mode fiber, G50/125 µm, OM4 (IEC 11801), IEC 60793-2-10 A1a.3, ITU-T G.651.1.
  • 100 % tested for insertion loss, return loss and end face geometry
  • all patch cords are provided with serial number, barcode and measurement protocol
  • all available variants can be created with the MTP® configurator
  • MTP® is a registered trademark of US Conec Ltd., USA

Resources

OpDAT patch cord MTP-F/MTP-F OM4, 8 fibres | 151SX8F8F0XXYView DataSheet
