Metz Connect 110931. EWIO2-MW M-Bus / WLAN

No reviews yet Write a Review
$0.00
Metz Connect 110931 EWIO2-MW
M-Bus / WLAN | American Cable Assemblies
Metz Connect 110931. EWIO2-MW M-Bus / WLAN
Metz Connect 110931. EWIO2-MW M-Bus / WLAN
Metz Connect 110931. EWIO2-MW M-Bus / WLAN
SKU:
MTZ110931
UPC:
4.25E+12
Availability:
Call for pricing and availability
Minimum Purchase:
1 unit
Current Stock:
RoHS:
compliant
EAN:
4251394629827

Frequently Bought Together:

Inc. Tax
Ex. Tax

Description

The EWIO2-MW is a powerful data logger for the energy consumption monitoring and energy monitoring in buildings, on machines, plants and systems. Two Ethernet ports with a Daisy Chain function for the chain further Data logger and a WLAN interface are available for the connection to the LAN or WLAN network. In addition, the WLAN interface can be used as an access point for the configuration with a mobile device (e.g. smartphone, tablet, notebook). The system is parameterised, configured and commissioned through a platform-independent web browser. The M-Bus and Modbus RTU interfaces enable to read different meters: e.g. electricity, water, gas and heat. Optionally, the measured values can either be sent from the data base (push) or read out (pull) via mail (SSL) or FTP (SFTP). Simple functions and control tasks in building or industrial automation can be created and visualized via the graphic programming interface "Node-RED" integrated in the web interface and the numerous digital and analog I/Os. An integrated µSD memory card expands the range of functions of the EWIO2-MW for save settings, data and applications.

Resources

EWIO2-MW M-Bus / WLAN | 110931View DataSheet

Specifications

General Data
Operating voltage 24 V DC +/- 10%
Power consumption (max.) 550 mA
Operating temperature -5 °C to +55 °C
Network 2 x RJ45 LAN 10/100BaseT, (Daisy Chain) WLAN, b/g/n, 2,4 GHz
Protocol TCP/IP
Controller NXP i.MX7D Dual Core, ARM-A7, 1 GHz, RAM 512 MB / Flash, max. 32 GB / ext. 2 GB µSD
Operating system Linux embedded
Interfaces Extension bus, max. 6 MR-I/O bus modules, Modbus RTU, max. 32 participants, M-Bus (DIN EN 13757-T1,2,3), max. 80 M-Bus charges
I/Os 8 x digital inputs, 3 x analog universal inputs, 8 x digital outputs, 3 x analog outputs
