The BACnet MS/TP module in IP65 housing with 4 digital inputs was developed for decentralized switching tasks. It is suitable for detecting potential-free switch states, for example electrical limit switches on vent valves or auxiliary contacts of power contactors. The inputs can be operated by means of potential-free switches or contacts or used as voltage inputs. The inputs can be scanned by means of standard objects via a BACnet client. The module address and the baud rate are set by means of two address switches.
Resources
Specifications
General Data | Protocol | BACnet MS/TP |
| Addressing range | 00 to F9 |
| Bus interface | RS485 (two-wire bus) |
| Transmission rate | 9600 to 115200 bit/s |
| Operating voltage | 24 V AC/DC +/- 10% (SELV) |
| Current consumption | 64 mA (AC) / 35 mA (DC) |
| Relative duty cycle | 100 % |
| Inputs | 4 x digital |
| Input / voltage | 30 V AC/DC |
| Input / high signal | more than 7 V AC/DC |
| Display | Green, red and yellow LED |
| Dimensions (W x H x D) | 160 x 40.7 x 120 mm |
| Weight | 350 g |
| Operating temperature range | -5 °C to +55 °C |
| Storage temperature range | -20 °C to +70 °C |
| Ingress protection for housing / terminal blocks | IP65 / IP20 |
