Sold Out
Metz Connect

Metz Connect 11066170. KRS-F-E06 H 24 V AC/DC

No reviews yet Write a Review
$0.00
Metz Connect 11066170 KRS-F-E06 H 24 V AC/DC | American Cable Assemblies
Metz Connect 11066170. KRS-F-E06 H 24 V AC/DC
Metz Connect 11066170. KRS-F-E06 H 24 V AC/DC
Metz Connect 11066170. KRS-F-E06 H 24 V AC/DC
SKU:
MTZ11066170
UPC:
4.25E+12
Availability:
Call for pricing and availability
Minimum Purchase:
1 unit
Current Stock:
Manual control facility:
yes
Connection type:
Spring clamp terminal blocks
RoHS:
compliant
EAN:
4251394628394

Frequently Bought Together:

Inc. Tax
Ex. Tax

Description

The threshold gate switches units, pumps, fans, burners, etc. As soon as the input voltage reaches the switching threshold, the relay is activated. When the input voltage falls below the switch-off threshold, the relay is released again.

  • Connection with spring clamp terminal blocks (push-in)
  • with manual control level

Resources

KRS-F-E06 H 24 V AC/DC | 11066170View DataSheet

Specifications

General Data
Operating voltage 24 V AC/DC
Current consumption 24 V AC 80 mA
Current consumption 24 V DC 16 mA
Threshold voltage 3.0 V DC
Switch-off voltage 2.5 V DC
Output / voltage 250 V AC
Output / contact 1 x changeover contact (SPDT)
Output / contact material AgSnO2
Output / continuous current 6 A
Output / switching frequency 1200 cycles/h
Mechanical endurance 1 x 107 switching cycles
Electrical endurance 1 x 105 switching cycles
Display Yellow LED
Dimensions (W x H x D) 17.5 x 61.3 x 60 mm
Weight 70 g
Operating temperature range -10 °C to 50 °C
Storage temperature range -25 °C to 70 °C
Ingress protection for housing / terminal block IP40 / IP20
