Description
Transistor couplers are used for switching DC loads.
- Connection with screw-type terminals
- Protective diode
Resources
| KRE-M4/1 DC | 1106302517 | View DataSheet |
|---|
Transistor couplers are used for switching DC loads.
| KRE-M4/1 DC | 1106302517 | View DataSheet |
|---|
| Input / operating voltage | 24 V DC |
|---|---|
| Input / power consumption | 10 mA |
| Output / switching voltage | 4 to 48 V DC |
| Output / continuous current | 0.8 A |
| Output / current pulse | 2 A / 1 s |
| Cross-section | 2.5 mm |
| Display | Green LED |
| Dimensions (W x H x D) | 11.2 x 61.3 x 43 mm |
| Weight | 35 g |
| Operating temperature range | 0 °C to +50 °C |
| Storage temperature range | -10 °C to +70 °C |
| Ingress protection for housing / terminal block | IP40 / IP20 |
