ILME is a globally recognized leader in the heavy duty industrial connector industry. For those harsh environments where the temperature is to great for the standard aluminum die cast enclosures (Hoods/Bases,) ILME offers a High-Temp solution. Using the same patented stainless steel locking system with die cast levers, in conjunction with special paint and gasket, this series can withstand temperatures up to 180C. Hoods and surface mount bases come with a wide range of PG, Metric, or NPT openings to meet your specific application.
Resources
Product Specifications
| Product Type | Rectangular Connectors |
| ILME Series | CN |
| Component Type | Hood |
| Housing/Insert Type | Standard |
| Lever Type | Double Latch |
| Hood Entry | Top |
| Hood Thread | M32 |
| Enclosure Dimension | 44.27 |
| Number of Entries | 1 |
| Gasket/O-Ring | No |
| Insert Dimension | 44.27 |
| Gender | Male |
| Cover | No |
| Upper AWG | N/A |
| Lower AWG | N/A |
| Enclosure Material | Metal |
| Temperature Range in Degrees Celsius | -40 C to +125 C |
| IP Rating | IP65/IP66/IP69 |
| Weight (lbs.) | 0.441000 |
