Mencom DeviceNet junction blocks provide passive connectivity (no electronics) allowing for multiple devices to plug into one convenient location. The simple plug and play design of these products drastically reduce installation time and minimizes down time. These products are offered in 4, 6, 8, 10, and 12 port configurations with a wide variety of home run options. Wired for DeviceNet applications, these blocks work well with a full range of cables and accessories from Mencom for DevicNet applications.
Resources
Product Specifications
| Product Type | Junction Blocks |
| Mencom Series | DeviceNet Block |
| Component Type | Junction Block |
| Pin Count | 5 |
| Number of Ports | 8 Port |
| Port Coupling | M12 |
| Port Thread Gender | Female |
| Home Run Connector | MIN Size I |
| Mating Thread / Type Head 1 | 7/8-16UN2 |
| Home Run Coupling | 7/8UN2 |
| Home Run Pin Count | 5 |
| Gender | Male |
| Circuit | DeviceNet |
| Wire Gauge | 15/17 |
| Upper AWG | N/A |
| Lower AWG | N/A |
| Voltage Rating | 120 |
| Amperage Rating | 10 |
| Cable Length in meters | 0.3 |
| Cable Length in feet | 1 |
| Color Code | DeviceNet |
| Cable Jacket Material | PVC |
| Cable O.D. | 0.44 |
| Jacket Color | Gray |
| Shell / Coupling Nut Material | N/A |
| IP Rating | IP67 |
| Weight (lbs.) | 0.512000 |
