Description
Japan to C5 power cord: Japan JIS C 8303 standard 3 pin plug to IEC C5 with VCTF 0.75mm² black wire, 6 feet with Japan PSE approval.
| Attribute | Specification |
|---|---|
| Male Plug | Japan JIS C 8303 3 prong 7A |
| Female Receptacle | IEC60320 C5 3 prong 7A |
| Wire Jacket Standard | VCTF |
| Gauge | 0.75mm² |
| Conductors | 3 wire |
| Copper Wire Stranding | 30 strands of 0.18mm² |
| Jacket Material | PVC |
| Temperature Rating | Up to 60°C |
| Wire Outer Diameter | 6.7mm |
| Conductor Color Code | Black, White and Green with Yellow Stripe / JCC (Japan Color Code) |
| Voltage | Up to 125 Volts AC |
| Amperage | Up to 7 Amps |
| Color | Black |
| Number Per Carton | 80 |
| Carton Weight | 31 lbs (13.8kg) |
| Carton Dimensions | 15.75 X 11.8 X 9 inches (40 X 30 X 23cm) |
| Testing | 100% are individually tested for Hi-Pot (dielectric voltage withstand test), opens, shorts and pinout. |
| Certifications | Japan PSE |
| Environmental Compliance | RoHS, REACH, Sony Green Partner, ISO14001:2015, ISO9001:2015 |
| Country of Origin | China |
