Description
Key Features:
- Modern, high quality instrument enclosure
- Material - Aluminum die-cast: GD SI 12 / DIN 1725
- Shallow lid, deep body
- Captive stainless steel lid screws
- Enclosure can be mounted to wall or shelf after closing the lid
- Integrated 1.7 mm recess in lid for membrane keypads and front panels
- Silicone gasket standard. (-50ºC up to +140ºC)
- Dark grey plastic clip-on design covers - to hide mounting & lid screws (plastic - polyoxymethylene) - RAL 7016
- Complete with lid captivation devices
- Degree of protection: NEMA 4X, IP66
- UL Listed
- Textured polyester powder coat, light grey RAL 7035. (can be supplied unpainted on special order)
Specifications
| Packaging Type | box |
|---|---|
| Material | Aluminum (Die-Cast Alloy) |
| Color | Gray |
| IP Rating | IP66 |
| Product Category | Enclosures |
| Type | Thick Wall, Water-Tight |
| NEMA Rating | 1, 4, 4X, 12 & 13 |
