Hammond Manufacturing

Hammond Manufacturing R102-162-000 enclosure - diecast aluminum

No reviews yet Write a Review
$292.25
SKU:
R102-162-000
UPC:
623980948904
Availability:
Call For Availability 413 283 2515
Minimum Purchase:
1 unit
Current Stock:
Product Series:
R100 Series
Packaging Type:
box
UNSPSC:
39121301
REACH Compliant:
Yes
RoHS Compliant:
Yes

Frequently Bought Together:

Inc. Tax
Ex. Tax

Description

Key Features:

  • Material - Aluminum die-cast: G AI SI 12 / DIN 1775
  • Shallow lid, deep body
  • Captive stainless steel lid screws
  • Neoprene oil and petrol resistant gasket standard. (-40ºC up to +80ºC)
  • Degree of protection NEMA 4X, IP66, DIN 40050
  • Temperature Range (-40ºC up to +80ºC)
  • Single-channel Fastening System
  • Special developed external mounting feet made from zinc-die-cast. Can be turned through 90º. The fastening holes have engagement lugs for this purpose. (See accessories)
  • All sizes have inner blind holes.
  • An inner mounting panel - made of zinc-plated steel is also available (See accessories)
  • Textured polyester powder coat, beige RAL7032 or light gray RAL7035. (can be supplied unpainted on special order)
  • CSA certified, UL Listed, Type 4, for use with industrial control equipment.

Specifications

Packaging Typebox
MaterialAluminum (Die-Cast Alloy)
ColorBeige
IP RatingIP66
Product CategoryEnclosures
TypeThick Wall, Water-Tight
NEMA Rating1, 4, 4X, 12 & 13
Max. P.C. Board Length (mm)225.1
Max. P.C. Board Width (mm)144.9
