Description
Features
- Front and rear solid doors include an installed gland plate for cooling options. Doors open to 135°. Window door option available.
- Reinforced top panel with provisions for optional HDMELB lifting eye bolts.
- Frames can be joined together with an optional joining kit.
- A black, cellular neoprene gasket provides tight and secure seal protection from moisture, dust and air contaminants.
- Available in 42U and 47U mounting heights.
- Available 24" wide. 31.5" is available as a special order.
- Available in 31.5" and 39.37" overall depths.
- Includes adjustable depth mount rails.
Specifications
- Cabinet frame, doors and side panels are constructed in 14-gauge mild steel.
- Square hole 19" mounting rails are constructed in 12-gauge mild steel, include rack unit indicators, and are Zinc-plated to provide superior surface areas for equipment grounding.
- Tested to nearly double the suggested load rating of 1,500 lbs (680 kg).
- NEMA Rated for UL 508A Type 12 and CSA Type 12. Complies with NEMA Type 12 and IEC 60529 IP54.
- Lift-tested to 900 lbs (408 kg) of equipment load when used with our HDMELB lifting eye bolts.
- Grounding studs are provided on the frame as well as side panels and doors. Front and rear studs on cabinet frame conform to PET.
- Finished in textured RAL9005 black powder paint. Also available in textured light gray upon request.
- Meets PCI DSS (Payment Card Industry Data Security Standard) compliance requirements.
- TAA-compliant for GSA Schedule purchases.
- RoHS Compliant.
- Manufactured in North America within an ISO 9001:2015 certified facility.
Included Components
- Welded steel frame with factory-installed nylon levelling feet, ground studs, and mounting points for optional casters.
- Two (2) pairs of adjustable depth EIA compliant square hole punched mounting rails.
- Two (2) solid removable side panels.
- Two (2) solid doors with
- one (1) installed gland plate
- one (1) die-cast locking swing handle
- Two (2) door keys
- One (1) solid top panel.
- Two (2) bottom panels with gland plates
- Four (4) levelling feet
- Starter pack of CAGKIT1032-50 screws
Specifications
| Rack Units | 47 |
|---|---|
| Rack Type | Cabinet |
| Paint Color | RAL9005 Black |
| Rail Type | Square Hole with 10-32 Cage Nu |
| Drawing Sheet | Download Drawing Sheet |
