Description
Features
- Designed for drop in replacement of original units.
- Physically, parts were designed to look similar to original factory units (where possible).
- Material used & design specs. were kept as close as possible to the original part to preserve the stock "tone".
Specifications
| Primary Volts | 240V @ 50/60 Hz |
|---|---|
| Secondary 1 | 660Vct @ 138 mA |
| Secondary 2 | 50V Bias |
| Secondary 3 | 6.3V @ 3A |
| Secondary 4 | 5V @ 3A |
| Amp Mfr | Fender |
| Amp Model (Ref. Only) | DELUEX* |
| Chassis No. (Ref. Only) | 5A3, 5B3, 5C3, 5D3, 6G3, AB763 |
| Drawing Sheet | Download Drawing Sheet |
