Description
Features
- 117/234 VAC - 50/60 Hz. dual primary
- Secondaries are either center tapped (C.T.) or dual secondaries (see tables below) for added versatility.
- Open style, 4 hole frame chassis mount.
- Minimum 6" long leads or copper tabs with holes.
- Dual bobbin design - no electrostatic shield required.
- Class B insulation (130 degrees, C).
- Hi-Pot test of 2,000V RMS.
- UL listed (# E207860) Type 3AH
- CSA certified (# LR209651).
Specifications
| Power Rating (VA) | 150 |
|---|---|
| Secondary VAC RMS | 5.0 C.T. |
| Secondary Current (Amps) RMS | 30 |
| Drawing Sheet | Download Drawing Sheet |
