Description
Features
- Low profile mounting, dual - split bobbin design.
- Low primary to secondary coupling, balanced windings, no electrostatic shield required and low EMF radiation due to semi-toroidal design.
- Universal dual primary 115/230V - 50/60 Hz.
- High insulation - Hipot of 1,750V RMS.
- Class B insulation - 130 degrees C.
- C UL US recognized. UL file E207860
Specifications
| Power Rating (VA) | 24 |
|---|---|
| Secondary (RMS) Series | 34V C.T. @ 700ma |
| Secondary (RMS) Parallel | 17V @ 1.4A |
| Drawing Sheet | Download Drawing Sheet |
