Hammond Manufacturing

Hammond Manufacturing 226R Transformer, PCB mount, epoxy-cast, 20VA, 30V C.T. @ 670ma / 15V @ 1.33A, 226 series

No reviews yet Write a Review
$114.38
SKU:
226R
UPC:
623980267005
Availability:
Lead time - Stock items ship 1-2 Days
Minimum Purchase:
1 unit
Current Stock:
Product Series:
226-227-228 Series
UNSPSC:
39121301
REACH Compliant:
Yes
RoHS Compliant:
Yes
$114.38

Frequently Bought Together:

Hammond Manufacturing 226R Transformer, PCB mount, epoxy-cast, 20VA, 30V C.T. @ 670ma / 15V @ 1.33A, 226 series
Inc. Tax
Ex. Tax

Description

Features

  • Primary 115 VAC, 60 or 400Hz. models, 3 case sizes
  • Epoxy cast to withstand shock and severe environments
  • Two coil design provides balanced windings and low magnetic radiation - no electrostatic shield required.
  • 228 series include four, 6-32 X .38 machine screw inserts for less strain on p.c. board connections.

Specifications

Power Rating (VA)20
Secondary (RMS) Series30V C.T. @ 670ma
Secondary (RMS) Parallel15V @ 1.33A
Frequency (Hz)400
Temp Rise (C)35
% Regulation7.5
Drawing SheetDownload Drawing Sheet
