Description
Features
- Designed for drop in replacement of original units.
- Physically, parts were designed to look similar to original factory units (where possible).
- Material used & design specs. were kept as close as possible to the original part to preserve the stock "tone".
- Output transformers marked UPGRADE (below) allow for more versatility by added secondary connections that did not exist on the original units.
Specifications
| Primary Impedance (Ohms) | 4,000 C.T. |
|---|---|
| Secondary Impedance (Ohms) | 8, 16 |
| Amplifier Type | Push-Pull |
| Watts | 30 |
| Winding Type | Bobbin |
| Original Amp Mfr | Vox |
| Amp Model Name(s) (Ref. Only) | AC30 Reissue |
| Drawing Sheet | Download Drawing Sheet |
