Description
Features
- Primary 115 VAC, 60 Hz.
- All secondaries center tapped, VAC (RMS)
- Enclosed, 4 hole chassis mount.
- Minimum 6" long leads.
- Dual bobbin design - no electrostatic shield required.
- Class B insulation (130 degrees C).
- Hi-Pot test of 2,000V RMS.
- UL listed (# E50394) & CSA certified (209651).
Specifications
| Power Rating (VA) | 27.5 |
|---|---|
| Primary VAC | 115 VAC, 60 Hz. |
| Secondary (RMS) VAC | 55 C.T. |
| Secondary (RMS) Amps | 0.5 |
