In Stock
Hammond Manufacturing

Hammond Manufacturing 166C12 Power transformer, low voltage, 115V 60 Hz., 0.63VA, 6.3/12.6 C.T., .1/.05A

No reviews yet Write a Review
$29.99
SKU:
166C12
UPC:
623980225906
Availability:
Lead time - Stock items ship 1-2 Days
Minimum Purchase:
1 unit
Current Stock:
Product Series:
166 Series
UNSPSC:
39121301
REACH Compliant:
Yes
RoHS Compliant:
Yes
$29.99

Frequently Bought Together:

Hammond Manufacturing 166C12 Power transformer, low voltage, 115V 60 Hz., 0.63VA, 6.3/12.6 C.T., .1/.05A
Inc. Tax
Ex. Tax

Description

Features

  • Economical single primary 115 VAC, 60 Hz. (or 117 50/60 Hz. see table) - (If you require 117/234 or 50/60 Hz. operation or dual secondaries check out our versatile 266Series.
  • Most secondaries are center tapped (C.T.), VAC (RMS) - see table for details.
  • Open style, channel bracket, two hole chassis mount.
  • Minimum 6" long leads.
  • Dual bobbin design - no electrostatic shield required.
  • We use Class B insulation (130 degrees, C) for extra protection - UL listed as a Class A (105 degree, C) design
  • Hi-Pot test of 2,000V RMS.
  • UL listed.
  • CSA certified.

Specifications

Power Rating (VA) 0.63
Primary VAC 115V 60 Hz.
Secondary (RMS) VAC 6.3/12.6 C.T.
Secondary (RMS) Amps .1/.05
Drawing Sheet Download Drawing Sheet
