Description
Key Features:
- Ideally suited for mounting of printed circuit boards horizontally.
- Molded in ABS plastic (material has a UL94-HB rating).
- Choice of three (3) lengths in five (5) colors. Stocked in black, grey. translucent clear, translucent smoke and translucent red.
- Satin texture finish.
- Cover is recessed for easy label installation.
- Complete with lid and two self tapping screws (plated for grey & clear, black for all other colors).
- Two (2) or four (4) P.C. board standoffs molded into interior depending on enclosure size (see drawings for details).
- Designed to meet IP54.
- For these same sizes pre-configured for a USB Type A male connector, try our 1551USB series.
- For slightly larger enclosures secured with (4) screws, try our 1551 series.
Notes:
- Extra self tapping lid screws are #2 x 1/2" (Plated - Qty 50 - Part number 1551USB50 and Black - Qty 50 - Part number 1551USB50BK)
- To secure P.C. board use self tapping #2 x 3/16" screws (Qty 100 - Part number 1553WTS100) - not included with enclosure.
Specifications
| Packaging Type | bag |
|---|---|
| Material | ABS Plastic |
| Color | Light Gray |
| Flame Rating | UL94 HB |
| IP Rating | IP54 |
| Product Category | Enclosures |
| Type | Miniature, general purpose |
| Max. P.C. Board Length (mm) | 25.5 |
| Max. P.C. Board Width (mm) | 59 |
| Drawing Sheet | Download Drawing Sheet |
