Description
Features
- Economical "open bracket" - channel mount.
- Tolerance of 15% on both inductance & resistance.
- Inductances measured at rated D.C. current.
- Minimum 5" long leads.
- Units will exhibit less inductance at slightly higher currents or more inductance at lower currents.
- Perfect for high voltage power supply filtering.
- Every unit is Hipot tested (100%) at 1,500 VAC
- Units are vacuum impregnated with polyurethane varnish for quiet and long life operation.
- For more sizes and voltages (enclosed type) - link here to our 193 Series.
Specifications
| Inductance Ls +/- 15% @ 0A D.C. (uH) | 8000 |
|---|---|
| Rated D.C. Current (Amps) | 1 |
| Minimum Inductance at Rated D.C. (uH) | 4500 |
| D.C> Resistance Max (Ohms) | 3.34 |
| D.C. Amps for 0.8 Ls | 0.7 |
