Description
Features
- Large ferrite core for extended saturation point, optimum frequency range .01-2 Mhz.
- 1.5" long leads (+/- 0.1")
- Test frequency 1 Khz.
- Core length 1.25"
- Coil is covered with vinyl insulation shrink sleeve.
- Operating Temperature -55 degrees C to + 135 degrees C
Specifications
| Inductance +/- 5% (uH) | 100 |
|---|---|
| Minimum Q | 10.5 |
| D.C. Resistance (Ohms) | 0.05 |
| Max D.C. Current (Amps) | 8 |
| Coil Diameter | 0.71 |
| Lead Diameter Gauge | 18 |
