Description
Features
- Designed with Nickel alloy cores for high performance and Wide Bandwidth
- Frequency Response: 20 Hz 20 kHz ±0.35 dB, (ref. @ 1 kHz)
- Low distortion at levels up to 27 dBu @ 20 Hz.
- Excellent Shielding Mu Metal enclosures
- Line Output Transformers are open style (not Mu Metal)
Specifications
| Impedance Ratio | 150:150:150 |
|---|---|
| Turns Ratio | 4.23611111111111E-02 |
| Max Input @ 20Hz | +2.0 dBu |
| THD @ 20 Hz. | 0.0003 |
| Frequency Response 20Hz / 20kHz | -0.08 dB/+0.06 dB |
| Drawing Sheet | Download Drawing Sheet |
