Description
| Male Plug | NEMA L22-30 |
| Female Connector | NEMA L22-30 |
| Cable Length | 7.6 Meter / 25 Feet |
| Tolerance | ± 80 mm / ± 3.2 inches for molded cords ± 150 mm / ± 6 inches for mechanical cords |
| Conductor Size | 8 Gauge AWG |
| Conductor Count | 5 wires |
| Conductor Color Code | Black, White, Red, Green | North American Color Code (NACC) |
| Outside Diameter | 23.7-24.1mm |
| Cable Jacket | North America SOOW |
| Jacket Material | NBR/PVC |
| Jacket Temperature Rating | 90° C |
| Color | Black |
| Testing | Each cord is tested for dielectric voltage-withstand (Hi-Pot), polarization and continuity. |
| Packaging | Coiled |
| Weight | 5.6 lbs |
