Description
Connect your Neutrik opticalCON DUO APC singlemode cables to APC LC fiber optic connectors with these handy in-line adapters by Camplex. Rugged yet lightweight design is perfect to strap to cameras and other gear. Each channel is clearly numbered and 1 meter in length with Techflex protective tubing for years of professional use. Supplied with opticalCON rubber dust cap for maximum protection.
opticalCON DUO adapters feed out to two (2) LC/APC individual fiber cable channels.
-
Features:
- Single Mode Cable
- Lightweight Design
- Numbered Channels
- (2) LC/APC Connectors
- Rubber Dustcap for Connector Protection
-
Specifications:
- Neutrik NO2-4FDW-A:
- Contact Resistance: < 7 mΩ
- Dielectric Strength: 1,5 kVdc
- Insulation Resistance: > 2 GΩ (initial)
- Rated Current Per Contact: 6 A
- Rated Voltage: < 50 V (1)
- Insertion Force< 45 N
- Withdrawal Force: < 45 N
- Lifetime: > 5000 mating cycles
- Chassis Shape: D
- Contacts: Bronze (CuSn6)
- Insert: Polyamide (PA 6, PBT 30 % GR, PBT 50 % GR)
- Shell: Zinc diecast (ZnAl4Cu1)
- Shell Plating: Black Chromium
Camplex APC LC to APC LC Single Mode Duplex Fiber Optic Patch Cable: - 9æm core and 125æm cladding
- Insertion Loss: ≤0.30dB max (PC, UPC) / ≤0.20dB max (APC)
- Return Loss: ≤45dB (PC) / ≤55dB (UPC) / ≤65dB (APC)
- Tensile Strength: Long Term: 160N / Short Term: 300N
- Pressive Strength: Long Term: 300N / Short Term: 1000N
- Bend Radius (mm): Dynamic: 80mm / Static: 40mm
- Attenuation: @1310nm: ≤0.3dB/km / @1550nm: ≤0.3dB/km
- Temperature: -20°C ~ 80°C
Resources
| Download the OPADAP Datasheet |  Â Download |
|---|
