Description
Incorporate multiple laser wavelengths or multiple fiber modes into your network with the Camplex CMX-FMC-6001 SFP to SFP Fiber Media Converter. This handy device delivers flexibility two SFP (Small Form-Factor Pluggable) slots for fiber to fiber mode and wavelength conversion which can provide tremendous costs savings to the alternative of replacing a fiber optic card.
Each SFPs supports speeds up to 1.25Gbps. Units are housed in a vented, black powder-coated steel cabinet with four LED indicators for power and fiber connection. Functions as a standalone converter, rack-mounted, or chassis-based. Compliant with IEEE802.3z & 802.3ab, CE, FCC, and RoHS standards.
SFPs Not Included
-
Features:
- Convert Fiber to Fiber Mode and Wavelength
- Supports 2 SFPs (Small Form-Factor Pluggable) with Identical Speeds up to 1.25Gbps
- Compact, Black Powder-Coated Steel Cabinet
- Four LED Indicators for Power and Fiber Connection
- Compliant with IEEE802.3z & 802.3ab Standards
- Certification: CE, FCC, and RoHS
- Compatible with MSA SFP+ SFP's
SFPs Not Included
-
Specifications:
- Data Rate: 100Mbps to 1250Mbps
- Standards: IEEE802.3z/ab. 1000Base- SX/LX/EX/ZX
- Transmission Distance: SFP Dependent
- Wavelength: SFP Dependent
- Supports Single Mode & Multimode
- Interface: Two SFP ports
- Input voltage: AC 110V~240V, DC 5V+2A, DC-48, DC24V, DC12V
- Power Consumption: 10W
- Dimensions: 3.75 x 2.75 x 1 inch / 95 x 70 x 25mm
-
Item Includes:
- 5V/1A power supply
-
Warranty:
- 1 Year
Resources
| Download CMX-FMC-6001 Product Manual (PDF) |  Download |
|---|
