Description
| Male Plug | NEMA L6-20 |
| Female Connector | IEC320 C21 |
| Cable Length | 4.5 Meter / 15 Feet |
| Tolerance | ± 80 mm / ± 3.2 inches for molded cords ± 150 mm / ± 6 inches for mechanical cords |
| Conductor Size | 12 Gauge AWG |
| Conductor Count | 3 wires |
| Conductor Color Code | Black, White, Red, Green | North American Color Code (NACC) |
| Outside Diameter | 11.9-12.3mm |
| Cable Jacket | North America SJT |
| Jacket Material | PVC |
| Jacket Temperature Rating | 105° C |
| Color | Black |
| Testing | Each cord is tested for dielectric voltage-withstand (Hi-Pot), polarization and continuity. |
| Packaging | Customer Specified |
| Weight | 2.708 lbs |
