Description
Bussmann TB300-10BS Terminal Block
Bussmann Terminal Block Strips and Barrier Block, Double Row, 600 V, 30 A, 10 Pole, 22 to 12 AWG Wire, Threaded Terminal, 9/16 in Spacing, 16 in-lb, Panel Mount, Screw, -40 to 130 deg C, Thermoplastic, Black, 6.62 in L x 1.33 in W x 0.81 in H
Additional Description: BUSS-TB300-10BS BARRIER BLOCK
Catalog Description: Eaton Bussmann TB300 series panel mount terminal block connector, Breakdown voltage 7500V, 600V, 30A, Barrier, Ten-pole, Black, Tin-plated brass terminal, nickel-plated brass SEMS philslot screw
Specifications
| UNSPSC | 39121410 |
|---|---|
| Amperage Rating | 30 |
| Amperage Rating | 30 A |
| Color | Black |
| Connection type | Screw |
| Dimensions | 6.62 in L x 1.33 in W x 0.81 in H |
| Material | Thermoplastic |
| Mounting type | Panel |
| Number of Poles | 10 |
| Spacing | 9/16 |
| Spacing | 9/16 in |
| Temperature Rating (Degrees F) | -40 to 130 |
| Temperature Rating (Degrees F) | -40 to 130 deg C |
| Terminal Type | Threaded |
| Torque Rating | 16 |
| Torque Rating | 16 in-lb |
| Type | Double Row |
| Voltage Rating | 600 |
| Voltage Rating | 600 V |
| Wire Size | 22 to 12 |
| Wire Size | 22 to 12 AWG |
