Description
Bussmann TB200-08
Bussmann Terminal Block, 8-Pole Double Row Standard, Series: TB200, 300 V, 30 A, 22 to 12 AWG Wire, 7/16 in Center Spacing, #6-32 Screw, 9 in-lb, Panel Mount, #6-32 TPI Screw, -40 to 130 deg C, Brass/Steel/Thermoplastic, Black, 4.25 in L x 1.12 in W x 0.56 in H
Additional Description: UNDR-TB200-08 (N) DBL ROW TERM BLOCK TERMINAL BLOCK CONN NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann TB200 series panel mount terminal block connector, Breakdown voltage 4800V, 300V, 30A, Double row, barrier, Eight-pole, #6-32 TPI Screw, Screw, Black, Tin-plated brass terminal, Zinc-plated Steel philslot screw
Specifications
| UNSPSC | 39121410 |
|---|---|
| Amperage Rating | 30 A |
| Color | Black |
| Connection type | #6-32 TPI Screw |
| Dimensions | 4.25 in L x 1.12 in W x 0.56 in H |
| Material | Brass/Steel/Thermoplastic |
| Mounting type | Panel |
| Screw Size | #6-32 |
| Series | TB200 |
| Temperature Rating (Degrees F) | -40 to 130 deg C |
| Torque Rating | 9 in-lb |
| Type | 8-Pole Double Row Standard |
| Voltage Rating | 300 V |
| Wire Size | 22 to 12 AWG |
