Description
Bussmann S506-800-R
Bussmann Time Delay Fuse, Low Breaking Capacity, Series: S506, Non-Indicating, Non-Rejection, 800 mA, 250 VAC/32 VDC, 35 A Interrupt, 50 Hz, Ferrule Terminal, Clip/Holder Mount, Cylindrical Body Type, Single Element, Glass, 5 mm Dia x 20 mm L Body Size
Additional Description: BUSS-S506-800-R S506 800mA BUSS FUSE
Catalog Description: 800MA 250V 5mm x 20mm RoHS Compliant Glass, Time Delay Fuse
Specifications
| UNSPSC | 39121607 |
|---|---|
| Amperage Rating | 800 mA |
| Body Type | Cylindrical |
| Frequency Rating | 50 Hz |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 35 A |
| Material | Glass |
| Mounting type | Clip/Holder |
| Mounting type | Holder |
| Rejection/Non-Rejection | Non-Rejection |
| Series | S506 |
| Terminal Type | Ferrule |
| Type | Low Breaking |
| Type | Low Breaking Capacity |
| Voltage Rating | 250 VAC |
| Voltage Rating | 250 VAC/32 VDC |
