Description
Bussmann REN-15 Super-Lag Renewable Fuse
Bussmann Super-Lag Renewable Fuse, Non-Current Limiting Non-Indicating Time Lag, Series: REN, 15 A, 250 VAC, 10 kAIC Interrupt, Class: H, Ferrule End Terminal, Holder Mount, Cartridge Body Type, Dual Element, Melamine, 0.56 in Dia x 2 in L Body Size
Additional Description: BUSS-REN-15 SUPER LAG RENEW. FUSE 15/250
Catalog Description: Eaton Bussmann series REN fuse, Renewable fuse, Super lag, time lag, non current-limiting, Industrial and commercial structures, 15 A, Class H, Non-indicating, Ferrule end x ferrule end, 10 kAIC, Standard, 10, 250 V
Specifications
| UNSPSC | 39121605 |
|---|---|
| Amperage Rating | 15 |
| Amperage Rating | 15 A |
| Body Type | Cartridge |
| Class | H |
| Interrupt Rating | 10 |
| Interrupt Rating | 10 kAIC |
| Material | Melamine |
| Mounting type | Holder |
| Series | REN |
| Terminal Type | Ferrule |
| Terminal Type | Ferrule End |
| Type | Non-Current Limiting Non-Indicating Time Lag |
| Type | Non-Current Limiting Non-Time Delay Super Lag |
| Voltage Rating | 250 |
| Voltage Rating | 250 VAC |
