Description
Bussmann NOS-4 One-Time Fuse
Bussmann One-Time Fuse, General Purpose Non-Current Limiting, Series: NOS, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 4 A, 600 VAC, 50 kA Interrupt, Class: K5, Clip Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine, 0.81 in Dia x 5 in L Body Size
Additional Description: BUSS-NOS-4 (N) BUSS ONE TIME FUSE NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series NOS fuse, Supplemental one-time fuse, Non current limiting, Light duty circuit locations, 4 A, Class H,Class K5, Non-indicating, 50 kAIC at 600 Vac, Standard, 10, 600 V
Specifications
| UNSPSC | 39121605 |
|---|---|
| Amperage Rating | 4 |
| Amperage Rating | 4 A |
| Body Type | Cartridge |
| Class | K5 |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 50 |
| Interrupt Rating | 50 kA |
| Material | Melamine |
| Mounting type | Holder |
| Rejection/Non-Rejection | Non-Rejection |
| Series | NOS |
| Terminal Type | Clip |
| Type | General Purpose Non-Current Limiting |
| Voltage Rating | 600 |
| Voltage Rating | 600 VAC |
