Description
Bussmann NON-45 One Time Fuse
Bussmann One Time Fuse, Non-Current Limiting, Series: NON, Non-Indicating, Non-Rejection, 45 A, 250 VAC, 125 VDC, 50 kA Interrupt, Class: H/K5, Ferrule Terminal, Holder Mounting, Cylindrical Body, Single Element, Melamine, 0.81 in Dia x 3 in L Body
Additional Description: BUSS-NON-45 BUSS ONE TIME FUSE
Catalog Description: Eaton Bussmann series NON fuse, Supplemental one-time fuse, Non current limiting, Light duty circuit locations, 45 A, Class H, Non-indicating, Ferrule end x ferrule end, 50 kAIC at 125 Vdc,50 kAIC at 250 Vac, Standard, 10, 250 V, 125 Vdc
Specifications
| UNSPSC | 39121605 |
|---|---|
| Amperage Rating | 45 |
| Amperage Rating | 45 A |
| Body Type | Cylindrical |
| Class | H/K5 |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 50 |
| Interrupt Rating | 50 kA |
| Material | Melamine |
| Mounting type | Holder |
| Rejection/Non-Rejection | Non-Rejection |
| Series | NON |
| Terminal Type | Ferrule |
| Type | Non-Current Limiting |
| Voltage Rating | 250 VAC, 125 VDC |
