Description
Bussmann NON-125 Fuse
Bussmann Fuse, One-Time Non-Current Limiting, Series: NON, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 125 A, 250 VAC/125 VDC, 10 kAIC Interrupt, Class: H, Blade End Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine, 1.56 in Dia x 7.13 in L Body Size
Additional Description: BUSS-NON-125 BUSS ONE TIME FUSE
Catalog Description: Eaton Bussmann series NON fuse, Non current limiting, Light duty circuit locations, 125 A, Class H, Non-indicating, Blade end x blade end, 10 kAIC at 250 Vac, Standard, 1, 250 V, 125 Vdc
Specifications
| UNSPSC | 39121605 |
|---|---|
| Amperage Rating | 125 A |
| Body Type | Cartridge |
| Class | H |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 10 kAIC |
| Material | Melamine |
| Mounting type | Holder |
| Rejection/Non-Rejection | Rejection |
| Series | NON |
| Terminal Type | Blade End |
| Type | One-Time Non-Current Limiting |
| Voltage Rating | 250 VAC/125 VDC |
