Description
Bussmann NDN63-WH Terminal Block
Bussmann Terminal Block, Series: NDN, 600 V, 65 A, 3 Pole, 18 to 6 AWG Wire, Feed-Through Terminal, 9.52 mm Spacing, 35 in-lb, C-Rail/DIN Rail Mount, #10-32 Screw, 105 deg C, Thermoplastic, White, 1.17 in W x 1.67 in D x 1.45 in H
Additional Description: BUSS-NDN63-WH ASSEMBLY NO.15201-12
Catalog Description: Eaton Bussmann series NDN DIN-rail feedthrough, 600V, 65A, Three-pole, #10-32 TPI Screw, 35 mm DIN rail, C-rail, White
Specifications
| UNSPSC | 39121410 |
|---|---|
| Amperage Rating | 65 |
| Amperage Rating | 65 A |
| Color | White |
| Connection type | #10-32 Screw |
| Connection type | Screw |
| Dimensions | 1.17 in W x 1.67 in D x 1.45 in H |
| Dimensions | 1.45 in H x 1.17 in W x 1.67 in D |
| Material | Thermoplastic |
| Mounting type | C Rail/DIN Rail |
| Mounting type | C-Rail/DIN Rail |
| Number of Poles | 3 |
| Series | NDN |
| Spacing | 9.52 |
| Spacing | 9.52 mm |
| Temperature Rating (Degrees F) | 105 |
| Temperature Rating (Degrees F) | 105 deg C |
| Terminal Type | Feed-Through |
| Torque Rating | 35 |
| Torque Rating | 35 in-lb |
| Voltage Rating | 600 |
| Voltage Rating | 600 V |
| Wire Size | 18 to 6 |
| Wire Size | 18 to 6 AWG |
