Description
Bussmann NDN3-WH Terminal Block
Bussmann Terminal Block, Series: NDN, 600 V, 30 A, 3 Pole, 22 to 10 AWG Wire, Feed-Through Terminal, 7.62 mm Spacing, 18 in-lb, C-Rail/DIN Rail Mount, #6-32 Screw, 105 deg C, Thermoplastic, White, 23.9 mm W x 42.4 mm D x 33.3 mm H
Additional Description: UNDR-NDN3WH (N) Rail mount terminal block NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series NDN DIN-rail feedthrough, 600V, 30A, Three-pole, #6-32 TPI Screw, 35 mm DIN rail, C-rail, White
Specifications
| UNSPSC | 39121410 |
|---|---|
| Amperage Rating | 30 |
| Amperage Rating | 30 A |
| Color | White |
| Connection type | #6-32 Screw |
| Connection type | Screw |
| Dimensions | 23.9 mm W x 42.4 mm D x 33.3 mm H |
| Dimensions | 33.3 mm H x 23.9 mm W x 42.4 mm D |
| Material | Thermoplastic |
| Mounting type | C Rail/DIN Rail |
| Mounting type | C-Rail/DIN Rail |
| Number of Poles | 3 |
| Series | NDN |
| Spacing | 7.62 |
| Spacing | 7.62 mm |
| Temperature Rating (Degrees F) | 105 |
| Temperature Rating (Degrees F) | 105 deg C |
| Terminal Type | Feed-Through |
| Torque Rating | 18 |
| Torque Rating | 18 in-lb |
| Voltage Rating | 600 |
| Voltage Rating | 600 V |
| Wire Size | 22 to 10 |
| Wire Size | 22 to 10 AWG |
