Description
Bussmann NDN111A-WH Terminal Block
Bussmann Terminal Block, Feed-Through, Series: NDN, 600 VAC, 90 A, 3 Pole, 18 to 2 AWG Copper Wire, Screw Terminal, 0.635 in Spacing, 32 in-lb Torque, DIN Rail/C-Rail/Surface Mounting, #1/4-28 Screw Connection, 105 deg C, Thermoplastic, White, 1.44 in H x 1.87 in W x 1.71 in D Dimensions
Additional Description: BUSS-NDN111A-WH NDN111 ASSEM.W/DOVE TAIL
Catalog Description: Eaton Bussmann series NDN DIN-rail feedthrough, Dove-tail, 600V, 90A, Three-pole, 1/4 in-28 TPI Screw, 35 mm DIN rail, C-rail, base, White
Specifications
| UNSPSC | 39121410 |
|---|---|
| Amperage Rating | 90 |
| Amperage Rating | 90 A |
| Color | White |
| Connection type | #1/4-28 Screw |
| Dimensions | 1.44 in H x 1.87 in W x 1.71 in D |
| Material | Thermoplastic |
| Mounting type | DIN Rail/C-Rail/Surface |
| Number of Poles | 3 |
| Series | NDN |
| Spacing | 0.635 |
| Spacing | 0.635 in |
| Temperature Rating (Degrees F) | 105 |
| Temperature Rating (Degrees F) | 105 deg C |
| Terminal Type | Screw |
| Torque Rating | 32 |
| Torque Rating | 32 in-lb |
| Type | Feed-Through |
| Voltage Rating | 600 |
| Voltage Rating | 600 VAC |
| Wire Size | 18 to 2 AWG Copper |
