Description
Bussmann MV155F1CBX20E Fuses
Bussmann Fuse, Current Limiting E-Rated Medium Voltage Single Barrel, Series: MV155, Indicating/Non-Indicating: Non-Indicating, 20 A, 15.5 kV, 50 kAIC Interrupt, Class: E, Ferrule End Terminal, Tube Body Type, Silver Ribbon Element, Fiberglass Tube, 2 in Dia x 21-3/4 in L Body Size
Additional Description: BUSS-MV155F1CBX20E (N) MEDIUM VOLTAGE E-RATED NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series MV055 E-Rated medium voltage fuse, Current limiting, 20A, 50 kAIC Symmetrical Maximum interrupt rating, Silver ribbon element, Fiberglass tube, 1 barrel, 2 in diameter
Specifications
| UNSPSC | 39121626 |
|---|---|
| Amperage Rating | 20 |
| Amperage Rating | 20 A |
| Body Type | Tube |
| Class | E |
| Frequency Rating | 50/60 |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 50 |
| Interrupt Rating | 50 kAIC |
| Material | Fiberglass |
| Material | Fiberglass Tube |
| Response Time | 300 |
| Series | MV155 |
| Terminal Type | Ferrule End |
| Type | Current Limiting |
| Type | Current Limiting E-Rated Medium Voltage Single Barrel |
| Type | Type MV155 E-Rated Medium Voltage 1-Barrel |
| Voltage Rating | 15.5 |
| Voltage Rating | 15.5 kV |
