Description
Bussmann MDL-2-1/4-R Time Delay Fuse
Bussmann Time Delay Fuse, Electronic Small Dimension, Series: MDL, Non-Indicating, Non-Rejection, 2.25 A, 250 VAC/32 VDC, 100 A Interrupt, 60 min, 5 to 120 s Response, Ferrule Terminal, Clip/Holder Mount, Cylindrical Body Type, Single Element, Glass, 1/4 in Dia x 1-1/4 in L Body Size
Additional Description: BUSS-MDL-2-1/4-R (N) BUSS SMALL DIMENSION FUSE NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton MDL Series Time-delay fuse 2.25A, 250 Vac, 32 Vdc (self certified)
Specifications
| UNSPSC | 39121607 |
|---|---|
| Amperage Rating | 2.25 A |
| Amperage Rating | 2.5 |
| Body Type | Cylindrical |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 100 |
| Interrupt Rating | 100 A |
| Material | Glass |
| Mounting type | Clip/Holder |
| Rejection/Non-Rejection | Non-Rejection |
| Response Time | 60 min, 5 to 120 s |
| Series | MDL |
| Terminal Type | Ferrule |
| Type | Electronic Small Dimension |
| Type | Small Dimension Ferrule |
| Voltage Rating | 250 |
| Voltage Rating | 250 VAC/32 VDC |
