Description
Bussmann KT3-WH Sectional Terminal Block
Bussmann Sectional Terminal Block, Depluggable, 600 V, 40 A, 3 Pole, 22 to 8 AWG Wire, 9.91 mm Spacing, 18 in-lb, Surface Mount, #8-32 Screw, 105 deg C, Thermoplastic, White, 2.34 in L x 1.22 in W x 1.25 in H
Additional Description: BUSS-KT3-WH (N) Base Mount White Terminal Block NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series KT3 panel mount terminal block connector, 600V, 40A, Depluggable, Sectional, Three-pole, #8-32 TPI Screw, Panel, White
Specifications
| UNSPSC | 39121410 |
|---|---|
| Amperage Rating | 40 |
| Amperage Rating | 40 A |
| Color | White |
| Connection type | #8-32 Screw |
| Connection type | Screw |
| Dimensions | 1.83 in L x 1.24 W x 1.25 in H |
| Dimensions | 2.34 in L x 1.22 in W x 1.25 in H |
| Material | Thermoplastic |
| Mounting type | Base/Panel |
| Mounting type | Surface |
| Number of Poles | 3 |
| Series | KT3 |
| Spacing | 0.93 |
| Spacing | 9.91 |
| Spacing | 9.91 mm |
| Temperature Rating (Degrees F) | 105 |
| Temperature Rating (Degrees F) | 105 deg C |
| Terminal Size | #8-32 |
| Terminal Type | Threaded |
| Torque Rating | 18 |
| Torque Rating | 18 in-lb |
| Type | Depluggable |
| Type | EFSE Depluggable Sectional |
| Voltage Rating | 600 |
| Voltage Rating | 600 V |
| Wire Size | 22 to 8 |
| Wire Size | 22 to 8 AWG |
